Online Digital Nitrate ion Sensor Water Tester Probe SOutput Signal ensor CS6720AD

Short Description:

The electrochemistry sensor uses membrane potential to determine the activity or concentration of ions in solution. When it is in contact with a solution containing the measured ion, a membrane potential directly related to the ion activity is generated at the phase interface of its sensitive film and solution.The parameters that characterize the basic properties of ion-selective electrodes are selectivity,dynamic range of measurements, response speed, accuracy, stability, and lifetime.

Model NO.: CS6720AD
Power supply: 9-36VDC
Waterproof Grade: IP68
Trademark: Twinno
Housing material: POM

Send email to us Download as PDF

Product Detail

Product Tags

CS6720AD Digital Nitrate Sensor

Description

CS6720AD digital nitrate ion selective electrode is a kind of electrochemical sensor that uses membrane potential to

measure the activity or concentration of ions in the solution. When it comes into contact with the solution containing the ions which are to be measured, it will generate contact with the sensor at the interface between its sensitive membrane and the solution.
